CLEARAUDIO Compact Phono
COMPACT. FLEXIBLE. PHONO.
compact phono
The compact phono combines MM and MC amplification in a particularly compact format. With easy switching, low-noise circuitry, and precise RIAA equalization, it offers everything essential for clean and balanced vinyl playback.
€509.00
Παράδοση σε 1-3 μέρες
For MM and MC
The compact phono is designed for moving magnet and moving coil cartridges. Switching between the two operating modes is simple and done at the touch of a button.
With 47 kΩ / 100 pF for MM and 100 Ω / 100 pF for MC, it is suitable for a wide range of common cartridges.
Clean signal processing
The particularly low signal from a phono cartridge requires careful amplification and processing. The compact phono achieves this through a low-noise, two-stage circuit design and precise RIAA equalization.
With an RIAA accuracy of ± 0.5 dB at 20 Hz to 50 kHz and a total harmonic distortion of less than 0.0065%, it creates the technical prerequisites for clean and balanced playback.
Targeted reduction of disturbances
An integrated subsonic/ultrasonic filter reduces unwanted interference outside the relevant frequency range. This allows signal processing to focus on what matters for playback.
| MODE: | MM/MC switching via button press. |
| Integrated subsonic/ultrasonic filter. | |
| AMPLIFICATION AT 1 kHz: | 40dB (MM operation) 60dB (MC operation) |
| Input impedance: | 47 kΩ/ 100pF / MM mode 100 kΩ/ 100pF / MC mode |
| RIAA ACCURACY: | ± 0.5dB @ 20Hz – 50kHz |
| CRIMP FACTOR: | < 0.0065 % |
| SIGNAL/NOISE RATE: | 76 dB (A) (MM operation) 65 dB (A) (MC operation) |
| OVERTRUST STRENGTH: | 29 dB / MC |
| MAXIMUM OUTPUT VOLTAGE: | 10 V rms (1 kHz) |
| CUTTING CURRENT EQUALIZATION: | According to RIAA (time const.: 75 µs / 318 µs / 3180 µs) |
| CHANNEL SEPARATION: | > 80 dB @ 1 kHz |
| STARTING RESISTANCE: | 100 Ω |
| INPUTS: | asymmetrical (CINCH) |
| EXITS: | asymmetrical (CINCH) |
| PERFORMANCE RECORDING: | Maximum power consumption: 0.7 watts In operation: 0.7 watts No standby mode Switched off: 0.0 watts (power supply disconnected) |
| POWER SUPPLY: | ± 18 V DC / 300 mA (external plug-in power supply, plastic housing) |
| WEIGHT: | approx. 310 g (preamplifier) |
| DIMENSIONS (W/D/H): | approx. 80 x 115 x 26 mm |
| MANUFACTURER’S WARRANTY: | 2 years* |
| To take full advantage of the Clearaudio manufacturer’s warranty, please register your product online within two weeks of purchase atProduct and warranty registrationor return the fully completed warranty card to us. |
